Description
Product Information
Age Range:1-5 years
Dimensions/Weights
Product Height:
- Stander Support Frame: 15.4″
- Pivot Base (Unfolded): 20.3″
- Pivot Base (Folded): 20.3″
Product Width:
- Stander Support Frame: 15.4″
- Pivot Base (Unfolded): 23.2″
- Pivot Base (Folded): 23.2″
- Small Sandal: 3″
- Medium Sandal: 3.2″
Product Length:
- Stander Support Frame: 26.8″
- Pivot Base (Unfolded): 37.4″
- Pivot Base (Folded): 26″
- Small Sandal: 6.3″
- Medium Sandal: 8.3″
Product Weight:
- Stander Support Frame: 14.3 lbs.
- Pivot Base Weight: 14.3 lbs.
Product Angle Range:
- Prone: 90-70°
- Supine: 90-160°
Chest Support Height:21.7″-32″
Chest Width:6.3″-9″
(distance between laterals)
Hip Support Height:11.8″-20.8″
(footplate to mid-buttocks)
Hip Width:6.3″-9″
(distance between hip guides)
Distance Between Midline of Knees:5.5″-8.4″
Footplate Angle:
- Plantarflexion: 10°
- Dorsiflexion: 10°
Tray Height Range:
- Prone: 21.9″-31.5″
- Supine: 18.5″-31.5″
(footplate to top of tray)
Tray Angle Adjustment:
- Prone: 30°
- Supine: 40°
Recommended User Height:29.5″-43.5″
User Weight Capacity:48.4 lbs.
