Description
Product Information
HCPCS Code:E8000
Sizes:
- Frame Sizes 1-3
- Harness Sizes 1-6
Age Range:
- Frame Size 1: 1-5 years
- Frame Size 2: 4-11 years
- Frame Size 3: 9-16 years
- Harness Size 1: 1-4 years
- Harness Size 2: 2-6 years
- Harness Size 3: 5-9 years
- Harness Size 4: 8-12 years
- Harness Size 5: 12-15 years
- Harness Size 6: 16-18 years
Dimensions/Weights
Product Width:
- Frame Size 1: 22.5″
- Frame Size 2: 26.5″
- Frame Size 3: 28.5″
Product Length:
- Frame Size 1: 33″
- Frame Size 2: 36.5″
- Frame Size 3: 46.5″
Product Weight:Frame Weight
- Frame Size 1: 26.5 lbs.
Weight for Size 1 includes frame and upper support unit - Frame Size 2: 14.5 lbs.
- Frame Size 3: 21.0 lbs.
Upper Support Unit Weight
- Frame Size 1: Size 1 frame and upper support unit do not separate.
- Frame Size 2: 23 lbs.
- Frame Size 3: 24 lbs.
Waist at Navel Level:
- Harness Size 1: 18.0″ – 22.0″
- Harness Size 2: 19.5″ – 23.5″
- Harness Size 3: 21.5″ – 25.5″
- Harness Size 4: 23.5″ – 27.5″
- Harness Size 5: 27.5″ – 31.5″
- Harness Size 6: 31.5″ – 35.5″
User Saddle Height:
- Frame Size 1: 9.5″ – 16″
- Frame Size 2: 16″ – 24″
- Frame Size 3: 21.5″ – 32″
(inside leg)
Recommended User Height:
- Frame Size 1: 23″ – 34″
- Frame Size 2: 34″ – 47″
- Frame Size 3: 42″ – 59″
(measured from shoulder height to floor)
User Weight Capacity:Frame
- Frame Size 1: 55 lbs.
- Frame Size 2: 110 lbs.
- Frame Size 3: 176 lbs.
Harness
- Harness Sizes 1-3: 110 lbs.
- Harness Sizes 4-6: 176 lbs.
